Hanna Nutrient Analysis Photometer for Greenhouses and Hydroponics, Basic, 115V - HI83215-01

Item #:
HI83215-01
Brand:
Hanna Instruments
Hanna Nutrient Analysis Photometer for Greenhouses and Hydroponics, Basic, 115V - HI83215-01
$657.00
Qty

Discontinued

Send This Page to a Friend

Ask an Expert

Our tech experts are ready to help!

1-866-4 JJSTECH (1-866-455-7832)

Email Us
Share this product:
Hanna Nutrient Analysis Photometer for Greenhouses and Hydroponics, Basic, 115V - HI83215-01

Hanna Nutrient Analysis Photometer for Greenhouses and Hydroponics, Basic, 115V - HI83215-01

$657.00

Discontinued


HI83215-01 Nutrient Analysis Photometer for Greenhouses and Hydroponics, Basic, 115V by Hanna Instruments

Deciding which fertilizer to use can be overwhelming, but with a bit of knowledge you can be sure your garden will get the right amount of nutrients it needs. The first question you’ll need to answer is, “What analysis do I need?” The analysis is actually three numbers you see usually at the middle or bottom of fertilizer packages (for example 10-20-10). These numbers represent percentages of the three major nutrients plants need: nitrogen, phosphorus and potassium (NPK for short).

HI 83215 is a multiparameter bench meter that measures twelve methods in low, medium and high ranges essential for monitoring greenhouse and hydroponics operations. It’s three channels allow for a wide range of tests.

The optical system of HI 83215 is based on special subminiature tungsten lamps and narrow-band interference filters to guarantee both high performance and reliable results.

HI 83215 has powerful interactive user support that assists the user during the analysis process. A full tutorial is available in the Setup Menu, and the Help Menu provides assistance for every step in the measurement process. This meter can be connected to a PC via a USB cable, where the data can be managed with optional HI 92000 Windows® compatible software.

  • Light blocking cuvette holder
  • Backlit LCD
  • BEPS (Battery Error Prevention System) Alerts users in the event a low battery could effect readings
  • PC compatible via USB
  • Powered by rechargeable batteries or 12 VDC
  • Save and recall logged data at the touch of a button.
  • On-screen tutorial; with the tutorial function enabled, short guides relating to current operation are displayed.
  • HELP button; screen specific help can viewed at the touch of a button.
  • Method selection; users can easily select parameters via the Method button.
  • Setup button; instrument preferences such as backlight intensity and screen contrast can be changed via the setup button.

Order Information:

HI 83215-01 (115V) and HI 83215-02 (230V) is supplied with sample cuvettes and caps (4 ea.), sample preparation kit, cloth for wiping cuvettes (1), scissors, AC/DC power adapter and instruction manual

HI 83215C-100 kit includes 10 mL cuvettes with caps (4 ea.), 100 mL plastic beaker, 170 mL plastic beaker, 100 mL graduated cylinder, 60 mL syringe with screw rim, 5 mL syringe, funnel, filter discs (25), spoon, pipettes (2), carbon powder packets (50), and demineralizer bottle with filter cap for approximately 12 liters of deionized water.

Light Source up to 5 tungsten lamps with different narrow band interference filters.
Light Detector silicon photocell
Power Supply external 12 VDC power adapter or built-in rechargeable battery
Environment 0 to 50°C (32 to 122°F); max 90% RH non-condensing
Dimensions 235 x 200 x 110 mm (9.2 x 7.87 x 4.33")
Weight 0.9 Kg (2 lbs.)
Multi Parameter Specifications
Parameter Range Method Reagent Code
Ammonia HR 0 to 100 mg/L (ppm) Nessler HI 93715-01
Ammonia LR 0.0 to 10.0 mg/L (ppm) Nessler HI 93715-01
Ammonia MR 0.0 to 50.0 mg/L (ppm) Nessler HI 93715-01
Nitrate HR 0 to 300 mg/L (ppm) Cadmium Reduction HI 93728-01
Nitrate LR 0.0 to 30.0 mg/L (ppm) Cadmium Reduction HI 93728-01
Nitrate MR 0 to 150 mg/L (ppm) Cadmium Reduction HI 93728-01
Phosphorus HR 0 to 100 mg/L (ppm) Amino Acid HI 93706-01
Phosphorus LR 0.0 to 10.0 mg/L (ppm) Amino Acid HI 93706-01
Phosphorus MR 0.0 to 50.0 mg/L (ppm) Amino Acid HI 93706-01
Potassium HR 20 to 200 mg/L (ppm) Turbidimetric HI 93750-01
Potassium LR 0.0 to 20.0 mg/L (ppm) Turbidimetric HI 93750-01
Potassium MR 0 to 100 mg/L (ppm) Turbidimetric HI 93750-01
