Kanomax Digital Multi Meter - 3804-50

Item #:

3804-50

Brand:

Kanomax

Ask an Expert

Our tech experts are ready to help!

1-866-4 JJSTECH (1-866-455-7832)

Email Us

Share this product:

Description

3804-50 Digital Multi Meters by Kanomax

By adding capacitance measurement to all the basic DMM functions of AC/DC V,AC/DC A, resistance, diode, and continuity testing, you get the convenience of an all-purpose device that easily enables you to analyze the data, record max/min/avg val-ues, display the relative value and even calculate for 4-20mA in terms of percentage level.

Specifications

Measurement Mode	Dual integration
Maximum display count	9999
Sampling rate	7 times/s(V/A measurement, temperature) 14 times/s(Ω, Diode, Contact Check, 1 time/s (Hz) 4 times/s ( capacitance measurements)
Power supply, Continuous operating time	Approx. 30 hours (DC measurement, when the manganese battery is used) Approx. 60 hours (DC measurement, when the alkaline battery is used)
Dielectric strength	5.312kV AC for 15 sec, sine wave, between input terminals and case (50 Hz/60Hz)
Maximum input voltage	V terminal: 1000V DC/ 1000V rms (sine) or 2 10⁷V Hz Measurement category CAT II 1000V, CAT III 600V (anticipated transient over voltage 6000V)
Maximum input current	A terminal: Continuous up to 10 A AC/DC, μA.mA terminal: 1000 mA AC/DC
Dimensions	Approx. 83W × 178H × 58D mm (3.27 W 7.01"H × 2.2 "D) (including protective holster
Mass	Approx. 400 g (14.1 oz.) (including protective holster and battery)
Usage Environment	0°C to 40°C(32°F to 104°F) 80%RH or less (no condensation)
Storage Environment	-20°C to 60°C(-4°F to 104°F), 80%RH or less (no condensation)
Applicable Standards	Safety: EN61010; EMC: EN61326
Accessories	TEST LEAD 3851-10, Protective holster, Instruction manual, One 6LR61 alkaline battery (supplied)
