Extech 200MHz 1X/10X Oscilloscope Probe - TL620
Item #:
EXT-TL620
Brand:
Extech
Share this product:
200MHz 1X/10X Oscilloscope Probe.
Replacement Probe for MS6000 series Oscilloscopes
| Attenuation | X1, X10 |
| Input Resistance | X1: 1MΩ±2%, X10: 10MΩ±2% |
| Input Capacitance | X1: 85pF to 115pF, X10: 18.5pF to 22.5pF |
| Compensation Range | 15pF to 40pF |
| Bandwidth | X1: DC to 6MHz, X10: DC to 60Mhz/100MHz/200Mhz |
| Maximum Input Voltage | X1: <200VDC + Peak AC X10: <600VDC + Peak AC |
| Cable Length | 120cm (47") |
| Weight | 55g (0.15lb) |
| Operating Temperature | -10°C to 50°C (14°F to 122°F) |
| Storage Temperature | -20°C to 75°C (-4°F to 167°F) |
| Humidity | <85% RH |
