Milwaukee TDS Tester with ATC and 1 point manual calibration - CD610

Milwaukee TDS Tester with ATC and 1 point manual calibration - CD610

$27.00

CD610 TDS Tester with ATC and 1 point manual calibration by Milwaukee

The Milwaukee CD610 Total Dissolved Solids High Range (PPM) Pen is designed for aquariums, pools and education and many other applications. The CD610 helps make sure that you keep your fish tank water clean and healthy. It is a cost effective tool for teacher's science labs. Keep PPM in your target range to help your achieve better results.

DESIGN FEATURES

  • Measures Total Dissovled Solids (PPM) direct and with automatic temperature compensation.
  • Ideal range for aquariums and pools (0 to 10000 ppm).
  • Units in ppm easily convertable to μS/cm.
  • Factory calibrated with the ability to recalibrate if needed.
  • Automatic Temperature Compensation (ATC).
  • 350 hours continuous use (4 x 1.5V batteries included).
  • Simple one point calibration.

MAINTENANCE

EC/PPM electrodes can develop nutrient build up over time. To miminize build up, always rinse the probe in fresh tap or DI water after every use.

CONVERTING TDS TO EC

The Milwaukee TDS/PPM Pen, like all TDS meters, provides a reading measured in parts per million of contaminates per unit of volume in a solution.

TDS/PPM is often converted to uS/cm. Different scales include the 500 scale, 650 scale and the 700 scale.

Your TDS/PPM reading can be approximately converted to μS/cm as shown in the examples below.

1 ppm = 2 μS/cm on the 0.5 factor scale

1 ppm = 1.43 μS/cm on the 442 scale or .70 factor scale

Range: 0 to 10000 ppm
Resolution: 100 ppm
Accuracy@20°C (68°F): ±2% full Scale
Typical EMC Deviation: ±2% full Scale
Calibration: Manual, at 1 point through trimmer
Temperature Compensation: Automatic from 5 to 50°C (41 to 122°F), with ß=2%/°C
Environment: 0 to 50°C / 32 to 122°F; max RH 100%
Battery Type: 4 x 1.5V Alkaline (included)
Battery Life: Approx. 350 hours of continuous use
Calibration Solution: M10038B (25 sachets 20 mL ea.)
Dimensions: 6 x 1.2 x 0.95 inches (180 x 65 x 32 mm)
Weight: 3.5 ounces (0.99 g)
