CorDEX UT5000 ATEX/IECEx Certified Intrinsically Safe Thickness Gauge

UT5000 ATEX/IECEx Certified Intrinsically Safe Thickness Gauge by CorDEX

CorDEX Instruments UT5000 Intrinsically Safe thickness gauge with CorDEX CONNECT™ measures metal thickness for Non-Destructive Testing (NDT) and Predictive Maintenance (Pdm) on pipelines and fixed equipment within hazardous locations.

UT5000 is a next generation thickness gauge packed with proven technologies: CorDEX CONNECT™ uses RFID + Software to tag measurements with their location then organises the data, giving the engineer a view of the pipeline at any specific location; the unique corrosion mode feature helps identify spots of thinning; whilst MultiECHO™ technology helps to improve accuracy on uneven surfaces. Also incorporating Echo-Echo functionality, the UT5000 thickness gauge is able to take thickness readings through protective paints without having to remove the coating.

Designed for rugged environments, the shock resistant skin protects a 3.1 inch (8cm) colour screen and has easy-to-feel raised buttons. The intrinsically safe dual-element, 4MHz transducer is adjustable up to 8Hz with accuracy of +/- 0.05mm (0.01inch).

Features:

• Certified for Zone 1 IIC T4 hazardous areas
• High accuracy +/- 0.05mm, Range 3mm up to 100mm
• Full colour, backlit, multifunction display
• Stores up to 1000 measurements
• Echo-Echo Technology for reading through painted surfaces
• Features CorDEX CONNECT™ Software

UT5000 is supplied complete as standard with:

• UT5000
• Hard carry case
• 1 x Probe
• USB communication cable
• Couplant gel
• Battery Pack
• 2 x Wrist strap
• 5 x ATEX RFID tags
• 1 x Calibration Block
